M1000 1500 kg - 10000 kg

Robot designs suitable for your needs and high transport AMR Robot applications - Lars robot designs your robot for you and develops products with the qualities you need.


Performance Parameter (mm; kg)   Navigation types Laser Slam Natural Navigation
size customizable   type of battery Lithium Iron Phosphate (Lifepo4 )
Rotation diameter 1476 mm    battery capacity 48V/65Ah
Self-respect 1000 kg    Rated battery life 8h
Rated load 1500-10.000 kg    Charging time 1.5 h
Adapt to the largest bin size customizable   Cycle life Full 500 times
Lifting Height 60 mm   Crossing ability <5 mm
Single pick and place time 8 s   Ability <3mm
Minimum pick-up bin height customizable   Ability to cross the slope <3-5 %
Height of pick-and-place box customizable   Operating temperature 0-45 ℃
Carrying shelves     Lidar Obstacle Avoidance Yes
No-load speed <1.0 m/s   Collision detection bar (optional) Yes
Full load speed <0.8 m/s   Available e-stop 2 sides
positioning accuracy ±10 mm   Communication  Wifi/ 5G
Stop accuracy ±5 mm   Debugging Interface Open API
Stop angle accuracy ±1°   noise <70 dB
