M150 - 1500 kg

M150 - 1500 kg Product Features

Performance Parameter (mm; kg)   Navigation types QR code or Laser Natural Navigation Slam
size 1200*860*290 mm   type of battery Lithium Iron Phosphate (Lifepo4 )
Rotation diameter 1476 mm    battery capacity 48V/60Ah
Self-respect 280 kg    Rated battery life 8h
Rated load 1500 kg    Charging time 1.5 h
Adapt to the largest bin size 2000*2000 mm palet (length*width)   Cycle life Full 1000 times
Lifting Height 60 mm   Crossing ability <5 mm
Single pick and place time 5 s   Ability <3mm
Minimum pick-up bin height 300 mm   Ability to cross the slope <3-5 %
Height of pick-and-place box 360 mm   Operating temperature 0-45 ℃
Carrying shelves 10 shelves (3 meter)   Lidar Obstacle Avoidance Yes
No-load speed <1.2 m/s   Collision detection bar (optional) Yes
Full load speed <1.0 m/s   Available e-stop 2 sides
positioning accuracy ±10 mm   Communication  Wifi/ 5G
Stop accuracy ±5 mm   Debugging Interface Open API
Stop angle accuracy ±1°   noise <70 dB
M150 - 1500 kg Product Features
Product Advantages

Product Advantages

You can perform material transfer operations with AGV robots or new AMR robots. Get the opportunity to carry 1500 kg with the M150. Keep working even on deformed surfaces with advanced suspension. With camera integration, monitor your pallet types and the load on them via Lars traffic management program or WMS integration ERP system. Reach high speeds with SLAM natural navigation or QR navigation. Get fast mapping and advanced obstacle recognition thanks to 360 laser integration. Automatically take off alternate trajectory when encountering obstacle.



Industries:

Food

FMCG

Pharma

Textile

Logistics Application

  • Warehouse Logistics
  • Production Transfers
  • Intralogistics

Fast charging





1500 kg load with Quick Charge 1 Shift = 1 hour charge



High performance, sustainable production



Fast charging
